ABSTRACT
Mixing equipment has been used long time ago, and applied widely in the traditional processing industry such as chemical, petrochemical, light industry, medical industry, food, mining, papermaking, metallurgy and so on. Mixing equipment can be classified by many means. Horizontal type and vertical type can be classified according to the shaft seal's fixing method. Of the two type, the horizontal type means both the tank's axes and the shaft's spin axis are horizontal.
A new mixing equipment with the function of mixing and vibration. was designed in this paper on the basis of mixing equipment research home and abroad. It will be used in the flour mixing of food processing industry. This design has two transmission system. The one is comprised of belt pulley and gear to achieve the function of mixing, the other is comprised of belt pulley and cam to achieve the function of vibration.
The overall design of the mixing equipment's basic structure and its basic dimensions were presented, and in order to unfold the concept of design and analysis later, three-dimensional modeling was made by the software of PRO/ENGINEER, Then, the analysis examination to the design proposal was presented to guarantee mixing equipment's reliability.
