摘 要
介紹了軸承蓋冷沖壓成形過程，經過對軸承蓋的批量生產、零件質量、零件結構以及使用要求的分析、研究，按照不降低使用性能為前提，將其確定為沖壓件，用沖壓方法完成零件的加工，沖壓基本工序為：落料、拉深、沖孔，然后根據對工序的初步計算，確定工序數目，如沖壓次數，拉深次數，對工序順序的安排，一般根據各工序的變形特點，質量要求來確定，由于本工件為帶孔的落料、拉深件，因此先落料，再拉深，最后沖孔，根據生產批量和條件（沖壓加工條件和模具制造條件）確定工序組合，因為生產批量大，所以將各個工序組合在一起，并用復合模沖壓，這樣就提高了產品的生產率。通過充分利用現代模具制造技術對傳統機械零件進行結構改進、優化設計、優化工藝方法能大幅度提高生產效率，這種方法對類似產品具有一定的借鑒作用。
關鍵字：軸承蓋；沖壓；工序；生產批量；生產效率
ABSTRACT
Introduced to carry the bearing cover cold hurtle to press to take shape the process, pass by to the batch quantity production, spare parts quantity, the spare parts structure and usage request of carry the bearing cover of analysis, study, according to not lower to use the function as premise, is certain in order to hurtle to press the piece, it uses to hurtle to press the method to complete the spare parts to process, hurtling to press basic work preface is: Fall to anticipate, pull deep, hurtle the bore, then according to the initial calculation of the work preface, make sure the work ordinal number eyes, if hurtle to press the number of times, pulling the deep number of times, to the in proper order arrangement of the work preface, general transform the characteristics according to each work preface, the quantity request to certain, because of in order to take the bore to fall to anticipate, pull the deep piece, this work piece so fall to anticipate first, then pull deeply, blunt bore of end, according to produce the batch quantity and condition( hurtle to press to process the condition and molding tools to make the condition)s to make sure the work that the preface combine, because of produce the batch quantity big, so combine each work preface together, counteract compound the mold hurtles to press, raising the rate of production of the product thus. Pass to make use of the modern molding tool manufacturing technique to carry on the structure improvement to the traditional machine spare parts well, excellent turn the design, the excellent chemical engineering skill method ability the significant exaltation produces the efficiency, this kind of method to similar the product has to certainly draw lessons from the function.
Key words: bearing cover; stamping; process; Production batch; Production efficiency
目 錄
1 分析零件的工藝性 2
1.1 沖裁工藝性 2
1.2 拉深工藝性 2
2 分析計算確定工藝方案 4
2.1 計算毛坯尺寸 4
2.2 確定是否需要壓邊圈 4
2.3 計算拉深次數 5
2.4 確定工藝方案 6
3 主要工藝參數的計算 7
3.1 確定排樣、裁板方案 7
3.2 計算工藝力、初選壓力機 8
3.2.1 計算工藝力 8
3.2.2 初選壓力機 11
3.3 計算壓力中心 11
3.4 計算凸、凹模刃口尺寸及公差 12
4 模具的整體結構設計 14
4.1 模具結構形式的選擇 14
4.2 模具總體設計 14
4.3 模具工作部分尺寸計算 15
4.3.1 落料凹模 15
4.3.2 沖孔凸模 16
4.3.3 拉深凸模 16
4.3.4 凸凹模 16
5 模具的主要零部件結構設計 18
5.1 模架 18
5.2 模座 18
5.3 模柄 18
5.4 定位零件 19
5.4.1 擋料銷 19
5.4.2 導料銷 19
5.4.3 導料板 19
5.5 卸料裝置 20
5.5.1 固定卸料板 20
5.5.2 橡膠 21
5.6 其他支撐與固定零件 21
5.6.1 凸模固定板 21
5.6.2 導向零件 22
5.6.3 墊板 22
5.7 緊固件 22
6 確定沖壓設備 24
7 模具的裝配 25
7.1 復合模的裝配 25
7.2 凸、凹模間隙的調整 25
8 重要零件的加工工藝過程編制 26
結 論 28
致 謝 29
參考文獻 30 ...
