With the rapid development of industrial automation, microelectronic technology, sensor technology, control technology and mechanical manufacturing technics，robot plays more and more important roles in industrial applications. The industry manipulator is a new technology which in the modern automatic control domain , and already has became a important component in the modern machine manufacture production system. This new technology has developed rapidly, and becomes an emerging discipline- manipulator project gradually. The manipulator involves to mechanics, mechanics, the electric appliance hydraulic pressure and the barometric pressure technology, the automatic control technology, the sensor technology and the computer technology and so on scientific field, is an interdisciplinary comprehensive technology. This paper describes the application of robot, and focuses on the structure design of LCD panel module transplanting machine, which is used in LCD panel production process to transfer the liquid crystal panel module from one production line to another.
Firstly, the article introduces the applications of robot in the industrial production process, and briefly introduced the industrial robot design theory and methods. Secondly, a more comprehensive discussion of the structural design of transplanting machine using to transfer the LCD panel module is proposed, and then determine the transmission mode of the transplanting machine, complete structural design of the machinery rotating arm and the clamping parts and Select all the standard components. Finally, to complete modeling work of all parts, establish the whole assembly of the transplanting machine, and complete drawing works of engineering drawings and assembly drawings of all machine parts.
Key words : Robot; LCD panel module; Transplanting machine; Rotating arm; Clamping parts
