Abstract
The rapid development of the domestic vehicle market, saloon car is an important tendency of vehicle. However, with increasing of vehicle, security issues are arising from increasingly attracting attention, the braking system is one of important system of active safety. Therefore, how to design a high-performance braking system, to provide protection for safe driving is the main problem we must solve. In addition, with increasing competition of vehicle market, how to shorten the product development cycle, to improve design efficiency and to lower costs, to improve the market competitiveness of products, and has become a key to success of enterprises.
This paper mainly introduces the design of braking system. Fist of all, braking system’s development, structure and category are shown. Besides, this paper also introduces the designing process of rear brake, braking cylinder, parameter’s choice of main components braking and channel settings.
Key words: braking; brake drum;
目 錄
第1章 緒 論 1
1.1 制動系統設計的意義 1
1.2 制動系統研究現狀 1
1.3 本次制動系統應達到的目標 2
1.4 本次制動系統設計要求 2
第2章 鼓式制動系統分析 3
2.1 鼓式制動器分析 3
2.2 制動驅動機構的結構形式選擇 3
2.2.1 簡單制動系 5
2.2.2 動力制動系 5
2.2.3 伺服制動系 6
第3章 制動系統設計計算 9
3.1 制動系統主要參數數值 9
3.1.1 相關主要技術參數 9
3.1.2 同步附著系數的分析 9
3.2 制動器有關計算 10
3.2.1 確定前后軸制動力矩分配系數β 10
3.2.2 制動器制動力矩的確定 10
3.2.3 后輪制動器的結構參數與摩擦系數的選取 10
3.3 制動器制動效能因數計算 12
3.4 制動器主要零部件的結構設計 12
第4章 制動性能分析 15
4.1 制動性能評價指標 15
4.2 制動效能 15
4.3 制動效能的恒定性 15
4.4 制動時汽車的方向穩定性 15
4.5制動器制動力分配曲線分析 16
4.6 制動減速度 17
4.7 制動距離S 17
4.8摩擦襯片（襯塊）的磨損特性計算 18
4.9駐車制動計算 19
第5章 總 論 21
參考文獻 22
